Dimensions & Specifications

Height

8.5mm

Width

9.2mm

Length

10.7mm

Operating Temp.

-20.00° to 70.00°

Device Type

Electro-Mechanical

Rated Voltage (Vpk, Vp-p)

3

Resonant Frequency (kHz)

2.73

Minimum SPL (dB)

90

Coil Resistance (Ohms)

15

Capacitance (pF)

- N/A -

IP Rated

- N/A -

Temp. Grade

Standard

Shape

Round

Tolerance (dB)

- N/A -

Tolerance (kHz)

0.5

Operating Voltage Min

2

Operating Voltage Max

4

Rated Current Max (mA)

70

Tolerance (Ohms)

3

Tolerance (%)

- N/A -

Terminal Material

Au Plated Brass

Weight (g)

1

Additional Features

Side Firing, Thru-Hole
