Dimensions & Specifications

Height

9.5mm

Width

9.6mm

Length

9.6mm

Operating Temp.

-30.00° to 70.00°

Device Type

Electro-Mechanical

Rated Voltage (Vdc)

5

Resonant Frequency (kHz)

2.7

SPL (dB)

80

Rated Current Max (mA)

30

Tone Or Pulse Rate

Continuous

Temp. Grade

Standard

Shape

Round

Tolerance (kHz)

0.2

Operating Voltage Min (Vdc)

3

Operating Voltage Max (Vdc)

7

Terminal Material

Sn Plated Red Copper

IP Rating

- N/A -

Weight (g)

1

Additional Features

Top Firing, Washable, Thru-Hole
